Place of Origin: | China |
Brand Name: | Fable |
Model Number: | FUV-007 |
Minimum Order Quantity: | 1 set |
---|---|
Price: | negotiation |
Packaging Details: | Black Suitcase |
Payment Terms: | L/C, T/T, Western Union,Alipay |
Supply Ability: | 100 sets per month |
Wave Length Range: | 220-1000nm | Detector:: | Back-illuminated CCD Area Array Detector |
---|---|---|---|
Integration Time:: | 1ms-100s | Signal-to-noise Ratio:: | >1000:1; |
Resolution:: | 1.5nm; | Battery Capacity:: | Can Be Used Continuously For 3 Hours When Fully Charged |
Number Of Pixels:: | 2048×64 | INPUT: | AC100-240V 50/60Hz |
Fable Black UV Spectrometer Quickly Detect Absorption Peak Of Type Ia Natural Diamond At 415nm
Technical Parameter
Model Number: | FUV-007 |
Spectral effective measurement range: | 220-1000nm; |
Integration time: | 1ms-100s; |
Signal-to-noise ratio: | >1000:1; |
Resolution: | 1.5nm; |
Detector: | back-illuminated CCD area array detector, |
Number of pixels: | 2048×64 |
With TEC cooling: | up to -10℃; |
Battery capacity: | 15000mAh,can be used continuously for 3 hours when fully charged; |
Charger: |
INPUT:AC100-240V 50/60Hz, OUPUT: DC25.2V, 4A; |
Dimensions: | 496mm×394mm×185mm; |
Weight: | 13.8kg. |
1: It can nondestructively detect various types of jewelry and jade.
2: determine the species, genesis (natural, synthetic, etc.) and optimization treatment characteristics of jewelry and jade materials.
3: Quickly judge a natural diamond by detecting the absorption peak of Type Ia natural diamond at 415nm
4. Can automatically capture the phosphorescence spectrum;
5. Two Measurement methods: reflection integrating sphere type and reflection fiber probe type
6. There are no restrictions on sample shape, size, etc., and no sample preparation is required.
